Thermal
|
|
Detector Type
|
Vanadium oxide uncooled focal plane detector
|
|
Effective Pixels
|
256 (H) × 192 (V)
|
|
Pixel Pitch
|
12 μm
|
|
Spectral Range
|
8 μm–14 μm
|
|
Sensitivity (NETD)
|
≤40 mK@f/1.0
|
|
Focal Length
|
2 mm
|
|
Field of View
|
H: 84.8°
V: 61°
|
|
Thermal Focus Control
|
Fixed-focal
|
|
Close Focus Distance
|
0.2 m (0.65 ft)
|
|
Aperture
|
F1.0
|
|
Digital Detail Enhancement (DDE)
|
Yes
|
|
Thermal AGC
|
Auto; Manual
|
|
Thermal Noise Reduction
|
2D NR; 3D NR
|
|
Image Flip
|
Mirror/180°
|
|
Color Palettes
|
18 (white hot/black hot/fusion/rainbow/golden autumn/midday/iron red/amber/jade/sunset/icefire/painting/pomegranate/emerald /spring/summer/autumn/winter)
|
|
Temperature Measurement Range
|
Low temperature mode:
–20 °C to +150 °C (–4 °F to +302 °F)
High temperature mode:
0 °C to +550 °C (+32 °F to +1022 °F)
Auto mode
|
|
Temperature Measurement Accuracy
|
Max. (±2 °C, ±2%)
Operating temperature: –20 °C to +50 °C (–4 °F to +122 °F)
|
|
Temperature Measurement Mode
|
Spot: 12
Line: 12
Area: 12
Supports 12 rules simultaneously
|
|
Visible
|
|
Image Sensor
|
1/2.8″ CMOS
|
|
Max. Resolution
|
2336 (H) × 1752(V)
|
|
Pixel
|
4 MP
|
|
Horizontal Definition
|
Center ≥150 TVL
Edge ≥100 TVL
|
|
Min. Illumination
|
Color: 0.01 lux
B/W: 0.001 lux
0 lux (white light on)
|
|
Visible AGC
|
Auto; manual
|
|
Visible Noise Reduction
|
2D NR; 3D NR
|
|
S/N Ratio
|
>55 dB
|
|
White Balance
|
Auto; manual; indoor; outdoor; tracking; sodium lamp;
street lamp; natural
|
|
Electronic Shutter Speed
|
1 s–1/30,000 s (auto/manual)
|
|
BLC
|
Yes
|
|
WDR
|
Yes
|
|
HLC
|
Yes
|
|
Digital Zoom
|
Yes
|
|
Day/Night
|
Color; B/W
|
|
Iris Control
|
Auto
|
|
Image Flip
|
180°
|
|
Exposure Compensation
|
Yes
|
|
Focal Length
|
2 mm
|
|
Field of View
|
H: 93.4°
V: 69.53°
|
|
Close Focus Distance
|
0.2 m (0.66 ft)
|
|
Optical Zoom
|
Fixed
|
|
Aperture
|
F2.0
|
|
Illuminator On/Off Control
|
Auto; Manual
|
|
Illumination Distance
|
4 m (13.1 ft)
|
|
Audio and Video
|
|
Video Compression
|
H.265; H.264M; H.264H; H.264B;M-JPEG
|
|
Resolution
|
Thermal:
Main stream: 1280 × 960; 1280 × 768; 640 × 480; 256 × 192; 1280 × 960 (default)
Sub stream: 640 × 480; 256 × 192; 256 × 192 (default)
Visible:
Main stream: 2336 × 1752; 1080p (1920 × 1080; 720p (1280 × 720); D1 (704 × 576); 2336 × 1752 (default)
Sub stream: D1 (704 × 576); CIF (352 × 288); 352 × 288
(default)
|
|
Video Frame Rate
|
Thermal (50 Hz & 60 Hz):
Main stream: 1 fps–25 fps, 25 fps by default
Sub stream: 1 fps–25 fps, 15 fps by default
Visible (50 Hz & 60 Hz):
Main stream: 1 fps–25 fps, 25 fps by default
Sub stream: 1 fps–25 fps, 15 fps by default
|
|
Audio Compression
|
G.711a; G.711mu; PCM
|
|
Image Encoding Format
|
JPEG
|
|
Function
|
|
Sound and Light Alarm
|
White light alarm prompts
|
|
Network Protocol
|
HTTP; HTTPS; TCP; ARP; RTSP; RTP; UDP; RTCP; SMTP; FTP; IPv4/v6; NTP; Multicast; SFTP
|
|
Region of Interest (RoI)
|
Yes (customizable)
|
|
Regional Focus
|
Yes
|
|
Interoperability
|
CGI
|
|
Browser
|
IE: IE 8 and later
Chrome: 42 and earlier
Firefox: 42 and earlier
|
|
User/Host
|
Up to 6 (total bandwidth: 64 MB)
|
|
Security
|
Authorized username and password; attached MAC address; encrypted HTTPS; IEEE 802.1x; controlled network access
|
|
User Management
|
Up to 6 users; supports multi-level user permissions (2
levels): management group and user group
|
|
Malfunction Detection
|
Network disconnection detection; IP conflict detection
|
|
Fusion Mode
|
Warm color; cold color; fuse with iron oxide red
|
|
PIP
|
Yes
|
|
Intelligence
|
|
Cold/Hot Spot Trace
|
Yes
|
|
Port
|
|
Network Port
|
1 × RJ-45 (10/100 Base-T)
|
|
Alarm Input
|
1
|
|
Alarm Output
|
1
|
|
RS-485
|
1
|
|
Alarm Output
|
1
|
|
Power
|
|
Power Supply
|
12 VDC ± 20%; PoE (802.3af); ePoE
|
|
Power Consumption
|
Basic: 3 W (12 VDC)
Max: 5 W (white light on, adapter excluded)
|
|
ePoE
|
Yes
|
|
Environment
|
|
Operating Temperature
|
–20 °C to +50 °C (–4 °F to +122 °F)
|
|
Operating Humidity
|
≤95%
|
|
Storage Temperature
|
–30 °C to +60 °C (–22 °F to +140 °F)
|
|
Physical Characteristics
|
|
Protection
|
IP67
|
|
Reliability
|
Surge protection: 6 kV
Air discharge: 15 kV
Contact discharge: 8 kV
|
|
Structure
|
|
Product Dimensions
|
113.6 mm × 62.0 mm × 39.0 mm (4.47″ × 2.44″ × 1.53″) (L × W × H)
|
|
Packaging Dimensions
|
Protection box: 239 mm × 110 mm × 71 mm (9.41″ × 4.33″ × 2.80″) (W × L × H)
|
|
Net Weight
|
≤0.5 kg (1.10 lb)
|
|
Gross Weight
|
≤1.0 kg (2.20 lb)
|
|
Lens
|
Included
|
|
Bracket
|
Included:
Magnetic mount: RKN010-02
Optional:
Wall mount: PFB110W, 816W2
|
