The AXIS C1410 Mk II Network Mini Speaker (02838-001) brings professional audio communication to compact indoor spaces. With Power-over-Ethernet support, it integrates seamlessly into IP networks without the need for separate amplifiers or analog audio cabling.
The built-in 7 W Class-D amplifier drives a 2.5-inch broadband dynamic cone speaker, producing clear and intelligible voice reproduction with a frequency response of 100 Hz to 20 kHz and sound pressure levels up to 90 dB. This ensures strong audio coverage for wide areas such as corridors, waiting rooms, lobbies, and offices.
The unit includes a built-in microphone for two-way audio, remote health monitoring, and configurable pre-recorded message playback. A built-in PIR motion sensor (range up to 6 m) can trigger audio messages automatically — ideal for intrusion deterrence, customer engagement, or staff notifications.
With open IP standards (SIP, VoIP, VAPIX, etc.), the C1410 Mk II integrates easily with video management systems, access control, and networked intercom or paging systems. Compact and lightweight (approximately Ø182 mm × 52 mm, 600 g), it mounts easily on ceilings or walls.
Designed for reliability, scalability, and simplicity, the AXIS C1410 Mk II offers an ideal combination of network audio performance and intelligent automation for modern IP-based facilities.
Specifications
| Feature |
Specification |
| Speaker Driver |
2.5″ broadband dynamic cone |
| Amplifier |
7 W Class-D |
| Frequency Response |
100 Hz – 20 kHz |
| Maximum SPL |
Up to 90 dB |
| Coverage Angle |
Approx. 145° conical |
| Motion Sensor (PIR) |
Built-in; range up to 6 m |
| Network Interface |
RJ-45 10/100BASE-TX PoE (IEEE 802.3af/at Type 1 Class 3) |
| Power Supply |
PoE (IEEE 802.3af/at) |
| Environmental Rating |
Indoor (IP4X dust protection) |
| Operating Temperature |
–20 °C to +50 °C |
| Dimensions |
Ø182 mm × 52 mm |
| Weight |
Approx. 600 g |
| Software Features |
Built-in DSP, health monitoring, scheduling, live and pre-recorded messages |
| Warranty |
5-year manufacturer warranty |
Installer Tips
-
Power and network – Use a PoE switch or mid-span injector (Class 3) to power the unit. Use Cat5e or better cabling for stable network performance.
-
Mounting location – Install on ceilings or high walls for even sound dispersion. The 145° coverage angle provides broad sound distribution in medium-sized indoor areas.
-
Motion sensor use – Aim the PIR sensor away from strong light sources or air vents to avoid false triggers. Ideal for detecting movement in hallways, reception areas, or store aisles.
-
Audio setup – Adjust DSP and volume settings using AXIS Audio Manager Edge to ensure announcements remain clear over ambient noise.
-
Cable routing – Avoid running network cables near high-voltage wiring to reduce interference. Shielded cables are recommended for industrial settings.
-
Message configuration – Set up pre-recorded messages for automatic playback or connect to your VMS for event-based announcements.
-
Testing – Test speaker output and microphone performance after installation. Adjust equalization to match the acoustic environment.
-
Maintenance – Clean the speaker grille periodically and verify PIR and microphone function through the system interface.
-
Integration – Combine with Axis cameras or access control devices to create automated deterrence or information systems.
-
Environment – For best performance, install indoors only and avoid exposure to humidity or direct water spray.
Frequently Asked Questions (FAQs)
Q: Does the AXIS C1410 Mk II require a separate amplifier?
A: No. It has a built-in Class-D amplifier and speaker driver, making it a self-contained, PoE-powered device.
Q: Can it play pre-recorded messages as well as live audio?
A: Yes. The unit supports both live announcements and scheduled or event-triggered pre-recorded messages.
Q: Where is this speaker best used?
A: Ideal for indoor applications such as offices, hallways, retail stores, healthcare facilities, and waiting rooms.
Q: Can it integrate with other IP systems?
A: Yes. The speaker supports open standards like SIP, VoIP, and VAPIX, allowing integration with CCTV, access control, or paging systems.
Q: How much area does one unit cover?
A: A single speaker can provide effective coverage for small to medium rooms. For large areas, multiple units should be installed for even sound distribution.
Q: What is the purpose of the built-in PIR sensor?
A: The PIR motion sensor detects movement and can automatically trigger playback of warnings, greetings, or alerts.
Q: Is it suitable for outdoor use?
A: No. It is designed for indoor use only (IP4X rating).
Q: How is it powered?
A: The unit operates via Power-over-Ethernet (PoE) and does not require a separate power adapter.
